DTH Hammers & Button Bits
Button Bits
Relying on our expertise and profound knowledge of our team, we have been successful in carving a niche of ourselves as a prominent manufacturer and exporter of Button Bits. Manufactured in compliance with the industrial standard and norms, our offered bits are renowned for their features such as durability, longer life and outstanding quality. Our offered range of Button Bits is extensively used in mining industry. Moreover, we are offering this product to our clients at reasonable prices.
Specifications
| Model | Button Bit size (inch) | Button Bit size (mm) | Suitable Hammer |
|---|---|---|---|
| Panther | 4 | 102 | PANTHER kala |
| Kala, Cop. 4-2 | 4.5 | 114.5 | 45 |
| QL 40 | 5 | 127.0 | QL 40, Cop 42 |
| - | 6.5 | 165.0 | Cop 62, Kala 6, Kala 65 D |
| B 5325 | 7.0 | 178.0 | - |
| - | 6 | 152 | Kala 65 D, Kala 65V, Cop 62, Kala 6 |
| - | 6.5 | 165 | Kala 65 D, Kala 65V, Cop 62, Kala 6 |
| - | 7.0 | 178 | Kala 65 D, Kala 65V, Cop 62, Kala 6 |
| - | 8.0 | 203 | Kala 65 D, Kala 65V, Cop 62, Kala 6 |
| - | 8.5 | 216 | Kala 65 D, Kala 65V, Cop 62, Kala 6 |
| - | 9.0 | 228 | Kala 65 D, Kala 65V, Cop 62, Kala 6 |
HAMMER
HAMMER SIZES
Size Range: 3" - 12"
Outer Diameter: 68 mm to 273 mm
Length: 810 mm to 1560 mm
Weight: 16 Kg to 580 kg
Hole Size: 75 mm to 428 mm
Hammer Specifications
| Model | Hole Size mm/inch |
Body OD mm/inch |
Length mm |
Weight Kg |
Suitable Bits | Top Unit Thread | Air consumption & CFM Air Pr in PSI |
|---|---|---|---|---|---|---|---|
| PANTHER | 102-115 4-4.5 |
97 3.8 |
990 | 40 | Panther/ Cop 4 |
66mm*2 3/8* API |
1100, 150, 200, 250, 300 |
| KALA 45D | 115-126 4.5-5.0 |
98 3.9 |
965 | 37 | KALA45/ KRD50 |
66mm*2 3/8* API Reg Pin/Box |
180, 240 |
| KALA 65D | 165-177 6.5-7.0 |
147 | 1000 | 90 | KALA65/ KRD75 |
89mm/3 1/2" API |
210, 270, 330 |
| KALA 65V | 152-165 6-6.5 |
136.5 5.37 |
1330 | 110 | SD6, Crop 62, B5315 |
87mm/3 1/2" API |
400, 550, 720, 1080 |
